APW7 for Antminer
1. The power cord is not included, please find one with at least 10A from your local market.
2. The APW7 can deliver a maximum power of only 1000W if it is connected to a 110V mains power supply. To obtain the rated power of 1800W, the APW7 must be connected to a 220-240V mains power supply. Please check the mains power supply that is the standard in your region before ordering.
3. This batch of PSU comes with only 10 PCIe connectors so cannot be used with more than one Antminer.
4. For USD wire, please do upload the bank proof of transfer within 48 hours. If no proof of transfer is loaded within this time period, the order will expire.
5. All items added to cart are shipped according to the item with the latest shipping date in the cart. If you would like to receive an item earlier, please place a separate order for it.
6. Be sure to keep the original packing on hand when you get PSU, the original box should be used to return the PSU when you requesting RMA. Otherwise, it won't be honored.
7. To ensure the authenticity, high quality and full warranty coverage of products you purchase from us, we strongly suggest you to purchase through our official website (www.bitmain.com) only and we will only be responsible for products purchased through our official website. Please acknowledge that we do not have any authorized third party distributor and reseller in any region or country. We will not allow our products to be sold by individuals through phone call, email or any other method. It could be a scam if you place your order with anyone claiming to be an official Bitmain sales representative/distributor via email or Skype or on any other website other than our official website (www.bitmain.com). We do not have any obligation to provide you with any compensation or indemnification in case of scam caused by third parties. The terms and conditions of sales of our products on our official websites are the only binding version and we will not in any event match any preferential terms offered by any other unauthorized third party distributor and reseller.
| Output | DC Voltage | 12.0V |
| Rated Current(200-240V input) | 150A | |
| Rated Power (200-240V input) | 1800W | |
| Rated Current(100-140V input) | 67A | |
| Rated Power (100-140V input) | 800W | |
| Ripple & Noise | <1% | |
| Voltage Accuracy | 12.0-12.5V | |
| Line Regulation | <1% | |
| Load Regulation | <1% | |
| Setup Time | <2S | |
| Short Circuit Protection | >10mS | |
| Input | Voltage Range | 100-140 /200-240V AC |
| Frequency Range | 50/60Hz | |
| Power Factor | >0.99(full load) | |
| Leakage Current | <1.5mA（220V 50Hz） | |
| Protection | Low-voltage Input | 80-89V AC |
| Output Short Circuit | Yes | |
| Output Overcurrent | 150-200A | |
| Overheat Protection | Yes | |
| Environment | Operating Temperature | -20-60℃ |
| Operating Humidity | 20%-90%RH(non-‐condensing) | |
| Altitude | < 2000m | |
| Structure | Dimensions | 206*110*62mm |
| Weight | 2.0kg | |
| Cooling System | forced-‐air cooling | |
| Noise | 43DB |
APW7 Efficience Curve
